QRP POTA from 10 to 20 Meters with the Chameleon Tactical Delta Loop and Icom IC-705

I do my best to shake up each field activation I perform. Even if in some small way.

While it would be way more efficient to deploy the same radio and antenna combination at each park and summit I visit, I get a thrill out of trying different radio and antenna combinations.

I should add that I’m fully aware how fortunate I am to have a lot of radios and even more antennas to pair in various combinations. I keep reminding myself that building and buying radios and antennas is still cheaper than restoring a 1940s era Willys CJ-2A.

Recently, a reader reached out and asked my opinion about the Chameleon Tactical Delta Loop (CHA TDL) antenna. I think the TDL is a brilliant antenna system, actually, and the one I recommend the most from Chameleon because of its versatility.

Not only can it be deployed as a multi-band vertical delta loop but it has all of the parts needed to be an MPAS Lite vertical as well, save the counterpoise.

The CHA TDL comes with a 25 foot wire that connects the two 17′ whips into a loop configuration, but the clamps on the end of that wire can’t connect to the ground lug on the MPAS ground spike terminal as-is. That said, you could easily make a short connector cable or connection point that would allow the CHA TDL wire to clamp to the ground spike terminal. Else, of course, you could cut a dedicated 25′ counterpoise from pretty much any wire you might have around the shack.

You can buy the same counterpoise used with the MPAS Lite package, but it’s more affordable just to build your own since there’s no magic in the counterpoise. And, FYI, configured as the delta loop, there’s no need for a separate counterpoise; only if you configure it as a vertical.

This same reader also has an Icom IC-705 and an mAT-705 Plus antenna tuner. He was curious how well that combo might work with the CHA TDL. I knew that the combo would work well, but I thought, “why not try it?”

I realized that it has been ages since I last deployed the CHA TDL in the field.

Zebulon B. Vance Birthplace (K-6856)

Tuesday, February 28, 2023, was a gorgeous day weather-wise, although it was a bit gusty at times.

I arrived at K-6856 and decided to film the full set-up of the CHA-TDL.

For an antenna with a fairly large profile when deployed, it’s actually very compact, albeit a bit heavy (mainly due to the weight of the solid stainless ground spike and TDL hub). That said, I did take this same CHA TDL setup on an 11 mile round-trip SOTA hike once and didn’t find it too heavy.

I placed my Icom IC-705 on the table in the picnic shelter and connected the mAT-705 to it with a 2′ BNC-BCN RG-316 cable and the ATU control cable. Continue reading QRP POTA from 10 to 20 Meters with the Chameleon Tactical Delta Loop and Icom IC-705

Jens shares current, voltage, and power comparisons between the IC-705 and FT-818

Many thanks to Jens (DJ2GMS) who recently reached out to share results from some very simple tests he performed on the Icom IC-705 and Yaesu FT-818. Jens writes:

A comparison of the Yaesu FT-818 and the Icom IC-705 (no comments, just facts):

On ext. 10,1V the FT-818 only needs 32 mA more than the IC-705

IC-705 (342 mA):

FT-818 (374 mA):

Min ext. voltage for TX of the IC-705 is 10,1V (appr. 1,8 Watts)

With 10,1V the FT-818 delivers 5 Watts

Minimum ext. voltage for TX of the FT-818 is 8V (appr. 3,5 Watts)

Thanks for sharing this, Jens!

POTA in Poland: Damian activates five parks in five hours

Many thanks to Damian (SP9LEE) who shares the following field report:


Field Report: 5 Parks in 5 Hours

by Damian (SP9LEE)

Okay, to be totally frank with you and as not to lose your trust, I have to admit that the title, however technically 100% true, may be slightly misleading. If you’re wondering to what extent, I suggest you keep reading 😉

I live in Krakow, the second-biggest city in Poland, and I’ve always complained about not having enough green areas there. But starting my QRP outdoor adventure and joining the POTA program helped me realize that I couldn’t be more wrong. I live in the city center (20 minutes walking distance from the Main Square) and as it turns out, there are 11 POTA parks within a 20-minute drive (outside rush hours, of course), and around 30 if you decide to drive 40 minutes.

That’s just crazy, especially compared to the places where some POTA Brave Souls live, giving Thomas (K4SWL) as an example – a few dozen activated parks, but only a couple of them in close range. Mine I could reach by foot or bike! I don’t like to waste anything (not only tangible goods, but also opportunities or this great potential that a lot of nearby POTA parks give), so I rolled up my sleeves and started activating one by one in May 2022.

But when December 31 comes, it tends to provoke reflections of the happenings in the last year. This happened to me as well. I asked myself: “Hey, isn’t it also a waste if you have a few parks clustered and never try to do them all in one day?” As you read this, you already know what the answer was. I decided not to hesitate and do it as soon as possible, on January 2nd, 2023.

Since I’ve never tried to do more than one activation per day, I felt quite insecure. What I do like during an activation is to practice quick antenna deployments (this may be useful one day), then experiment with different antenna configurations (such as sloper angles, heights, azimuths, counterpoise placement), and finally make as many contacts as possible during a given time limit. This time limit is usually set by my family schedule or other errands I need to run.

As you can see, that’s the complete opposite to the requirements that RaDAR or POTA Rover awards make: proficient antenna deployment, gathering 10+ QSOs for a valid activation, collecting the equipment, and speedy drive to a next spot. Sounds challenging? But isn’t it what the New Year usually brings? It’s just a matter of making proper adjustments in one’s procedures and attitude. At least, that’s what I thought.

I picked three park entities 20-25 minute car drive from my home, which in total would give me 5 POTA references:

  • SP-0997 Kowadza Protected Area (3-fer)
  • SP-0994 Skołczanka Nature Reserve (3-fer)
  • SP-2274 Skawiński Obszar Łąkowy Natura 2000 (2-fer)

They are all located on the territory of Bielańsko-Tyniecki Lanscape Park (SP-0993) and/or  Dębnicko-Tyniecki Obszar Łąkowy Natura 2000 (SP-2122). So now you know why the title might be a bit misleading – I actually planned to take advantage of having 2- and 3-fers around and work 5 entities in total from only 3 different spots.

Kowadza Protected Area (SP-0997)

I hopped into the car just after I left home (yes, some of us have work or school duties… and some of us have a day-off to play radio!). I’ve never been to the Kowadza Protected Area, so even after researching it on Google Maps, I wasn’t sure what to expect. Besides my standard set, I also packed my fiberglass 6m fishing rod in case there was no convenient place to mount the antenna, and my portable PV panels in case the LiPo 5Ah battery died. Continue reading POTA in Poland: Damian activates five parks in five hours

Guest Post: QRP POTA Activation During the CQ World Wide Contest

QRP POTA Activation During the CQ World Wide Contest

by Joshua (KO4AWH)

I had an opportunity to activate Fort Yargo State Park (K-2177) during the CQ WW DX contest.

Fort Yargo is my local park, about 30 minutes away. The park features a great playground for the kids to play on and many tall trees which are perfect for deploying a wire antenna. There really is not much more I could ask for in a POTA location. Even the noise floor is very low, about S0, so I typically turn on the pre-amp which brings it up to S2-S3 on my Discovery TX-500.

This was very much a last minute plan. I knew the contest was going on which may present some difficulty activating QRP. I knew I would not be calling CQ on 20m where I normally activate and hunting stations could be difficult but likely doable.

There was a bit of rain at the house in the morning, then a promise of drizzle the rest of the day. Not too sure what I would find at the park, but hopefully the rain would hold off and I could get the activation in using the TX-500 without too much worry about it getting wet. I threw in a picnic blanket with a water barrier that promised a bit of protection from the rain if needed it.

I have a go-box setup with my TX-500 and IC-705, as well as several antennas, an ATU, and all cabling and power needed to run FT8 either on my Raspberry PI4 with the TX-500, or on my iPad through the IC-705.

I was taking my wife’s vehicle as she had the car seats needed for the 3 kiddos that were coming along. So, I had to be sure I had everything I needed. There are quite a few additional radio items I keep in the back of my car that I would not have available. But everything should be in the go-box, right?

Go-Box with two full stations, TX-500 and IC-705

After a bit of mist and some rain on the drive over, I planned to setup the TX-500 knowing it would get a bit wet. I tossed the throw line in the tree and pulled up my Tufteln EFHW QRP cut for 20m. In retrospect I probably should have pulled up the EFRW for a bit more band agility.

I tuned around for a few minutes.

Yup, there was not a single free place across 20 meters where I could start calling CQ in the clear. In fact, the stations I listened to for more than a few seconds had someone else start calling right on top of them. 20 meters was indeed crazy.

I could try to hunt some DX with my QRP signal, it would be a fight no doubt, and a nice challenge. After another DX station I tuned to had someone in the States start calling right over top of them, decided not to hunt. Continue reading Guest Post: QRP POTA Activation During the CQ World Wide Contest

How Joe keeps his Icom IC-705 cool during long FT8 sessions

Many thanks to Joe (KD2QBK) who writes:

Hi Thomas:

I’ve recently discovered QRP FT8, which I’ve been working with my Icom IC-705. I run with an end-fed sloper that runs out of my 2nd floor shack window using a 49:1 unun and a length of RG-58. I’m also using an Emtech ZM-2 tuner between the antenna and the radio when needed.

The set up works really nicely, except for the way FT8 heats up and overtaxes the radio after a while. Searching around a bit, I’ve found just the right solution for that issue. The AC Infinity MULTIFAN S1 USB-powered table fan.

https://amzn.to/3DvqemJ (affiliate link)

It’s basically just a 3-inch square fan like you’d find in a computer or some other electronic devices, with rubber “feet” attached. It can stand upright or lay flat depending on your need. it’s stated purpose is to cool or ventilate routers, game consoles, audio equipment, etc.

The AC Infinity MULTIFAN S1 includes a speed control switch and an inline USB socket to daisy-chain other devices. One caveat with the inline socket: because it’s placed in the line between the fan and the speed control switch, the switch must be set to high speed else the socket won’t have adequate power for the attached device.

All I do is plug the fan into a USB socket and place it at the rear of the radio, sans battery, to keep it cool. I have it set up to blow onto the radio. Obviously I need to power the radio with an external source when the battery isn’t attached. I’ve not tried to use the fan with the battery attached, but I don’t think it would help much. The ventilation slots next to the battery compartment don’t seem wide enough to let much air in. Continue reading How Joe keeps his Icom IC-705 cool during long FT8 sessions

QRPer Notes: IC-705 Firmware Update, New YouTube Channels, and ARRL Handbook 100th Edition

Because I receive so many tips from readers here on QRPer, I wanted way to share them in a concise newsletter format.  To that end, welcome to QRPer Notes, a collection of links to interesting stories and tips making waves in the world of radio!


IC-705 Firmware Update

Many thanks to Uli Zehndbauer who notes that Icom recently released a new firmware update for the IC-705.

Here are the details/notes about this firmware version from Icom:


Changes from Version 1.27

      • – Displays the Receiving (or Transmitting) route icon (RF or TM: Terminal mode) on the RX History Log and QSO Log
      • – Displays the Receiving (or Transmitting) route icon (RF or TM: Terminal mode) to the chunk information in the QSO audio file
      • – Displays the Receiving route icon (TM: Terminal mode) to the following screens;
        • RX HISTORY screen
        • GPS POSITION (RX) screen
        • QSO audio, PLAY FILES screen
        • QSO audio, FILE INFORMATION screen
      • – Improves the WLAN access point list so that you can delete the connected or saved access points
      • – Improves the CI-V command 1F 01 (DV transmit call sign) so you can set only the “UR” call sign without the other call signs.

Click here to download the firmware from the Icom website.


New CW YouTube Channels/Videos

In the past two weeks I’ve received a number of video links from QRPer readers who are featuring CW activations in their YouTube videos.

First up is Steve (K9NUD) who has started a new channel featuring his CW activations primarily using a cootie/sideswiper. Steve is doing something I wish I had the time to do which is add CW closed captions to his videos. This makes it easy to follow along. Check out this video:

Jonathan (KM4CFT) recently noted in the comments of my YouTube channel that he made a video of his third ever CW POTA activation. I had to check it out and am glad I did. You get a very good idea of what it’s like on the air as a CW newbie. In other words: not that bad at all! Incidentally, when I looked up Jonathan on QRZ, I discovered we have a mutual friend in Zach (KM4BLG).

Keep up the great work, Jonathan!

Chris (KD2YDN) sent me a link to the following video on his new YouTube channel. In the video I actually get to hear what my signal sounded like during his SOTA/POTA activation. He certainly captured some amazing morning scenery and a gorgeous sunrise from Westkill Mountain:

I think you should consider checking out these videos and subscribing!


The ARRL Handbook 100th Edition

The ARRL has announced pre-orders for their new ARRL Handbook. I feel like everyone should have a copy of the Handbook. It’s simply chock-full of useful information–much of which is simply timeless. I still reference the 1994 handbook my buddy Mike (K8RAT) gave me shortly after I got my license in 1997. I feel like it’s important to have reference material like this in paper.

As a side note, I’ve been to a number of shortwave radio broadcast transmitting stations and at each one of them I’ve seen the ARRL Handbook on the Chief Engineer’s shelf. Lots of great radio principles inside.

The book is $80 on pre-order. That’s a lot for a book, but it’s also a LOT of book!

Here’s the announcement from the ARRL:

We have arrived at a milestone. The 100th edition of The ARRL Handbook for Radio Communications is here: Handbook 100. How do you celebrate the most widely used one-stop reference and guide to radio technology principles and practices? By continuing to fill the pages of another edition with the progress and achievement of radio amateurs. Handbook 100 is written for everyone with a desire to advance the pursuit of wireless technology. Here is your guide to radio experimentation, discovery, and innovation.

What’s Inside

Each chapter is filled with the most up-to-date knowledge representative of the wide and ever-expanding range of interests among radio amateurs. There are practical, hands-on projects for all skill levels — from simple accessories and small power supplies to legal-limit amplifiers and high-gain antennas.

Key topics:

    • Radio electronics theory and principles
    • Circuit design and equipment
    • Signal transmission and propagation
    • Digital modulation and protocols
    • Antennas and transmission lines
    • Construction practices

Updated with new projects and content, including:

    • An all-new chapter on radio propagation covering a wide range of bands and modes
    • New and updated sections on electronic circuit simulation
    • New cavity filter and high-power HF filter projects
    • New coverage on digital protocols and modes
    • New material on RFI from low-voltage lighting and other sources
    • Revised sections covering new RF exposure limits
    • New content on portable station equipment, antennas, power, and assembly
    • New material on ferrite uses and types
    • New section on how to use portable SDR to locate sources of RFI …and more.

Click here for more information and to place an order.

Photos of Mike’s uber-organized Icom IC-705 field kit

Many thanks to Mike (2E1BFH) who shares the following photos of a new field kit he’s built around the Icom IC-705:





Continue reading Photos of Mike’s uber-organized Icom IC-705 field kit

Ken’s photos comparing five field radios

Many thanks to Ken (WW5A) who writes:

Hello Thomas-

I enjoy reading the posts on the QRPer. The size comparison photos recently posted got me thinking. I had taken a photo several months back of a X5105, 817, RS918 (McHF), G90 and a 705, basically to do the same thing (size comparison).

I have attached them for your amusement [click to enlarge]:

73,

Ken WW5A

Thanks for sharing these, Ken. To me, it’s interesting to see the comparison between the FT-817 and the G90. When I owned a G90 I didn’t have an 817 at the time for comparison. It reminds me just how long/deep that G90 was! Also interesting to see that the mcHF clone is a wee bit wider than the IC-705. Thanks for sharing!

Don adds an inexpensive clip-on LED lamp to his Icom IC-705

Many thanks to Don (W7SSB) who shares the following notes about a small LED book lamp he’s added to his IC-705 and Peovi cage:

This is a book lamp from Amazon that uses 3 AAA’s and costs $8.99.

It has 3 brightness settings and clips onto the Peovi cage.

It really brightens up the radio in a dark room.

Click here to check it out on Amazon (affiliate link).

Thank you for sharing this, Don!  That’s a clever use for that book lamp. I’ve often thought that all field radios ought to have a logging lamp on them like the KX1. This is a nice and inexpensive workaround!

QRP DX: Pairing the MM0OPX EFHW & Icom IC-705 during an impromptu activation

Turns out, if you go to Canada for nearly two months, when you return home you’re going to have about two months worth of catch up.

It’s all explained in one of Einstein’s theories. If memory serves, Einstein stated:

“One cannot simply ignore stuff for two months and expect no repercussions. Time lost must be accounted for due to the principles of the conservation of energy. Plus…what in creation were you thinking?”

When we returned from Canada in early August I had some pretty big plans about the parks and (especially) summits I would hit here in North Carolina. But after returning, I quickly realized I had so much work to do around the house and a number of DIY jobs I’d postponed at our investment property. They all immediately took priority.

Indeed, in the one month span after returning from Canada, I only performed three park and no summit activations. There was a three week period of time without activations of any sort. I simply didn’t have the time to fit anymore in my schedule. This all gave me a serious case of activation withdrawal.

If you’ve been following my field reports, you’ve no doubt noticed that I never do multi-hour activations at one site unless I happen to be camping at a POTA park.

I’m asked about this fairly regularly (why I don’t do longer activations to achieve Kilo awards, etc.) but the truth is I make POTA/SOTA fit in my busy family schedule. This often equates to short (30-60 minute) activation windows.

Then quite often, I’m on the road or doing errands in town and realize I have a short opening for an activation, so I squeeze it into the day. This is why I always have a fully self-contained field radio kit in my car. At a moment’s notice, I can set up a station, and play radio.

In a way, I find this style of quick activation fun, too. “Can I seriously validate a park during this short window of time–?”

These activations remind me of that scene in A Christmas Story where the father gets a small thrill out of timing himself as he changes a flat tire on the side of the road. I totally get that.

Except with me it’s deploying antennas instead of managing lug nuts.

Hamfest time!

Friday, September 2, 2022 was a big day for me. On the way back from visiting my folks that morning, I spent a couple of hours at the Shelby Hamfest.

The Shelby Hamfest typically has the largest outdoor tailgate market in all of North Carolina and likely one of the larger ones in the southeast US. I had no items on my wish list, I just wanted to see what was there.

This was the first hamfest I’d attended in a little over a year. It was a lot of fun and I got to meet a number of friends and readers/subscribers.

If you’d like to see the treasure I found at the Shelby Hamfest, by the way, check out the large photo gallery I posted over on the SWLing Post.

Back to the topic of impromptu activations…

South Mountains State Park (K-2753)

Driving home after the Shelby Hamfest that early afternoon, I realized I was passing dangerously close to the Clear Creek access of South Mountains State Park.

I had a couple of errands to run back home before the post office closed at 17:00 that day, but in my head I believe I had just enough time for a quick activation. The total amount of detour driving would only be about 15 minutes; I’d just need to keep the activation (including most set up and pack up) under 45 minutes or so.

At the last minute, I took a right turn and headed to the park!

Fortunately, the one lonely picnic table at the Clear Creek access was unoccupied.

I grabbed my IC-705 kit and a new antenna!

The MM0OPX QRP End-Fed Half-Wave (EFHW)

A few weeks prior, Colin (MM0OPX) reached out to me and asked if I would consider testing a new high-quality, highly-efficient QRP EFHW he’d designed.

Of course, there’s nothing new about an EFHW–it’s one of the most popular field antenna designs on the planet–but Colin’s goal was to make one with the lowest insertion loss possible in a compact, lightweight (50g), and durable format.

I say he succeeded.

In fact, this activation was actually the second one where I used Colin’s QRP EFHW. The previous day, I paired it with a then very Beta version of the Penntek TR-45L at Tuttle Educational State Forest (K-4861).

In short, the antenna made for a wildly successful QRP activation. Here’s the QSO Map (you’ll need to click and enlarge to see the number of contacts):

QSO Map from the previous day with the MM0OPX QRP EFHW

The Penntek TR-45L was still quite new at the time and even though  I got John’s (WA3RNC) blessing, I didn’t post the activation video and mini overview on YouTube. Keep in mind the TR-45L was still in Beta so not all features had been finalized.

I did, however, post the entire TR-45L activation video on Patreon.

Quick side note: Why this video only on Patreon?

As I mentioned in a previous post, I’ve now invested in a Pro account with Vimeo that allows me to post completely ad-free videos  that my Patreon supporters can enjoy and even download. I recently discovered that YouTube unfortunately inserts ads even though I have monetization turned off. I pay for Vimeo’s bandwidth and server space, so I also can control the ad experience completely (basically eliminating any possibility of ads!).

My Patreon supporters are the ones making it possible for me to pay the annual $420 fee to Vimeo and I am incredibly grateful, so I pass along the benefit to them.

Continue reading QRP DX: Pairing the MM0OPX EFHW & Icom IC-705 during an impromptu activation
